Horizontal large flow double suction split case water pump with control cabinet

Introduction:
The S series pumps are single stage, double suction; horizontal split case pumps designed for high volume water transfer in a wide range of applications. Centurion pumps are available in 43 sizes ranging from 80mm to 400mm discharge and capable of capacities up to 4000 cubic meters per hour and heads up to 160 meters. Centurion pumps offer ease of maintenance with simple assembly/disassembly (no requirement for special tools). All major wear components and replaceable parts are easily accessible and can be changed out with minimal effort and downtime, without removing the suction and discharge piping.
fire fighting pump.jpg

Application:
double volute water pump.jpg


Performance Curve:

River Dredging Pump.jpg

Pump Performance:

Pump ModelCapacity
 (m3/h)
Head(m)Motor Power
(kw)
Speed
(rpm)
NPSH
(m)
150S-50160503729503.9
150S-78160785529503.7
200S-42280424529506
200S-952809513229505.3
250S-14485143014503.8
250S-654856513214503.1
300S-907909031514504.2
350S-125126012571014505.4
400S-9016209056014506.2
500S-592020594509704.5
600S-753170759009706
800S-7655007616007306
800S-764400498005854.2

Construction Material:
S type pump could supplied in Cast iron, Ductile iron, Stainless steel material.

Part DescriptionCast IronDuctile IronStainless Steel
CasingAS1830/T260AS1830/300-17AS2074/H6B
ShaftAS2837/420
ImpellerAS2074/H6BAS1830/300-17AS2074/H6B
Shaft SleevesAS2074/H6B
Lantern RingAS1565/ALLOY 836BAS1830/T260AS2074/H6B
GlandAS1830/T260AS2074/H6B
Wearing RingAS2074/H6B
