3.5 Inch submers stainless steel deep well pump in pakistan
The Depump® QJ Deep Well Pump is vertical multistage submersible centrifugal pumps. The main parts of this pump are stainless steel material.It is mainly used for farmland irrigation and water supply for people and livestock in plateau mountainous areas and construction sites.
Features:
Installation, use and maintenance are convenient
Occupy small area and do not need to build pump house.
The structure is simple and the raw materials are saved.
| Conventional Deep Well Submerible Pump Models | |||||||
| Type | Pump Max. Dia. | Best Well Dia. | Rated Capacity | Head | Power | Speed | |
| (mm) | (mm) | (m³/h) | (m) | (Kw) | (r/min) | ||
| 150QJ | 143 | 200 | 5-40 | 28-330 | 4-45 | 2850 | |
| 200QJ | 184 | 250 | 20-100 | 20-500 | 4-110 | 2850 | |
| 250QJ | 233 | 300 | 50-200 | 30-600 | 5.5-220 | 2850 | |
| 300QJ | 281 | 350 | 180-370 | 30-500 | 30-450 | 2900 | |
| 350QJ | 330 | 400 | 300-450 | 30-240 | 63-450 | 2900 | |
| 400QJ | 377 | 450 | 400-650 | 40-200 | 75-450 | 1450 | |
| 600QJ | 700 | 600-1100 | 30-170 | 110-520 | 1450 | ||
| 800QJ | 900 | 1500-2200 | 30-75 | 250-710 | 1450 | ||
| High Pressure Deep Well Submerible Pump Models | |||||||
| Type | Pump Max. Dia. | Best Well Dia. | Rated Capacity | Head | Power | Speed | |
| (mm) | (mm) | (m³/h) | (m) | (Kw) | (r/min) | ||
| 98QJG | 98 | 150 | 1-15 | 300-3000 | 30-125 | 2850 | |
| 98QJG | 98 | 150 | 15-30 | 900-1500 | 30-125 | 2850 | |
| 118QJG | 118 | 150 | 1-30 | 300-3000 | 30-280 | 2850 | |
| 130QJG | 130 | 150 | 5-30 | 1500-3000 | 30-280 | 2850 | |
| 130QJG | 130 | 150 | 30-60 | 800-1500 | 30-280 | 2850 | |
