ISA High Efficiency Air-condition End Suction Clean Water Pump for Irrigation

Introduction: ISA series end suction centrifugal pumps are designed complying to BS EN733/DIN24255 standard. This series of pumps have great advantages in interchangeable parts, high quality and low cost, wide applications in plants, mines, city water suppliers, fire-fighting systems,...

Send InquiryChat Now
Product Details


Introduction:
ISA series end suction centrifugal pumps are designed complying to BS EN733/DIN24255 standard. This series of pumps have great advantages in interchangeable parts, high quality and low cost, wide applications in plants, mines, city water suppliers, fire-fighting systems, air-condition systems and irrigation.


Applications
● Water supply and drainage
● HVAC and Cooling Tower
● Marine-Ballasting& Bilge
● Booster and pressurization set
● Irrigation and agriculture
● Water supply and drainage
● Food and chemical industry
● Food and chemical industry (with stainless steel material)


Design $ Structure

Design

Performance and dimensions referring to the European standard BS EN733/DIN24255

Structure

Horizontal, Axial End-suction, Single-Stage, Single-Suction, Volute Casing, Back pull-out

DN (mm)

32-300

Flange

DIN2501 PN16 GB/T17274.6 PN1.6


Material

Part

Standard material

Option on request

Casing

Cast iron

Ductile Iron/SS304/SS316

Impeller

Brass

Cast iron/SS304/SS316

Shaft

ASTM420

SS304/SS316/45

Shaft seal

Mechanical Seal

Glad Packing


Technical Data

Flow Rate (Q)

4~1584m³/h

Head (H)

2~150m

Speed

1450 or 2900 rpm (50Hz)/1750 or 3500 rpm (60Hz)

Max Temperature

85℃ (standard); 105℃ (on request)

Working pressure

1.0MPa standard; 1.6MPa on request

Conveying Medium

Clean water or liquids similar to clean water in physical property





FAQ

Q: What kind of company you are?
A: Shijiazhuang Depon Pump Company is professional manufacturer in pumps. After accumulation and development of many years, we have formed a complete system of pump design, selection, application, manufacture, marketing and maintenance. We have passed CE, SGS certificate. Our customers are at home and abroad. Hope to coorperate with the worldwide friends.

Q: What's your MOQ?
A: Trial sample order is OK.

Q: What are your payment terms?
A: T/T, L/C, D/P, D/A or as customer required

Q: How about the warranty?
A: One year warranty for pumps, it depends on other pump working condition details.

Q: What is the delivery time?
A: 7-30 days according to customer quantities.

Q: Can you do OEM brand?
A: Yes, Welcome.

Q: What information should I offer to get pump solution?
1, Head: m
2, Flow: m3/h
3, Max Solid size: mm
4, Particle shape (smooth or sharp):
5, Medium pH level:
6, Specific Gravity of the Medium:
7, Temperature:
8, Drive type:
9, Power supply: Electric or Dlesel
10, Voltage and Frequency of the Motor:

Welcome inquiry!
