Mining Rubber Lined And Marine Horizontal Centrifugal Slurry Pump

Mining Rubber Lined And Marine Horizontal Centrifugal Slurry Pump

The Products are widely used in mining , power, metallurgy, coal , dredging, building material and other industrial lines to pump concentrate, tailing,sludge, and other abrasive high density slurry.

Send InquiryChat Now
Product Details

Mining Rubber Lined and Marine Horizontal Centrifugal Slurry Pump

MAH_02MAH_03

Basic Info

Max.Capacity: >400L/min

Impeller Number: Single-Stage Pump

Type of Impeller: Single Suction Pump

Pump Casing Combined: Vertical joint Surface Pump

Impeller: Closed

MOQ: 1 Set

Certificate: Ce

After Sales: Yes

Size: 1- 18 Inch

Head: 5 - 118m

Trademark: DE Or OEM

Specification: CE, SGS

HS Code: 8413709990

Max.Head: 80-110m

Driving Type: Motor

Working Pressure: High Pressure Pump

Position of Pump Shaft: Horizontal Pump

Mounting Height: Suction Centrifugal

Usage: Pump, Pumps, Condensate Pump, Ash Pumps, Circulating Pump, Slurry Pump

OEM: Accept

Pump Type: Centrifugal Slurry Pump

Color: As customers request

Capacity: to 5400 M3/H

Material: High Chrome Alloy or Rubber

Transport Package: Packed with Wooden Box or as Customer′s Request

Origin: Baoding, China


Performance Curve


slurry


Pump Structure


MAH_05



MAH SLURRY PUMP PERFORMANCE PARAMETERS


Type

Allowable Mating Max. Power(Kw)

Clear Water Performance

Impeller

Capacity/Q m3/hr

Head/m

Speed/rpm

Max Efficiency/%

NPSH/m

Nos of Vane

Impeller Diameter/mm

1.5X1-MAH

15

12.6--28.8

6--68

1200--3800

40

2--4

5

152

2X1.5-MAH

15

32.4--72

6--58

1200--3200

45

3.5--8

5

184

3X2-MAH

30

39.6--86.4

12--64

1300--2700

55

4--6

5

214

4X3-MAH

30

86.4--198

9--52

1000--2200

71

4--6

5

245

6X4-MAH

60

162--360

12--56

800--1550

65

5--8

5

365

8X6-MAH

300

360--828

10--61

500--1140

72

2--9

5

510

10X8-MAH

560

612--1368

11--61

400--850

71

4--10

5

686

12X10-MAH

560

936--1980

7--68

300--800

82

6

5

762

14X12-MAH

560

1260--2772

13--63

300--600

77

3--10

5

965

16X14-MAH

1200

1368--3060

11--63

250--550

79

4--10

5

1067

18X16-MAH

1200

2520--5400

13--57

200--400

85

5--10

5

 1370


Feature


· Bearing assembly- large diameter shaft with short overhang contributes to long bearing life.



· Liners – easily replaceable liners are bolted, not glued to the casing for positive maintenance.



· Casing – Casing halves of cast or ductile iron provide high operating pressure capabilities.



· Impeller – front and rear shrouds have pump out vanes that reduce recirculation and seal contamination.



· Throat bush – wear is reduced and maintenance simplified by the use of tapered.


Welcome to contact me for more details.

MAH_12
