The Depump® slurry pump is the world's standard for the most difficult mill duties. A wide variety of impellers and shaft seals provide a prefect fit for a wide rangeapplications. The Depump® slurry pump provides excellent wear life while maintaining... READ MORE
Features
·Bearing assembly- large diameter shaft with short overhang contribute stolong bearing life.
·Liners–easily replaceable liners are bolted, not glued to the casing for positive maintenance.
·Casing–Casing halves of cast or ductile iron provide high operating pressure capabilities.
·Impeller–front and rear shroud shave pump out vanes that reduce recirculation and seal contamination.
·Throatbush–wearis reduced and maintenance simplified by the use of tapered.
Performance Table
| Performance Of DP-MAH | |||||||
| Type | Max. power | Capacity | Head | Impeller | Max. particle size | ||
| Quantity of vanes | |||||||
| kw | (m³/h) | (m) | (mm) | ||||
| 1.5x1B-MAH | 15 | 3.6-21.6 | 6-65 | 5 | 14 | ||
| 1.5x2B-MAH | 15 | 7.2-48.6 | 5-62 | 5 | 19 | ||
| 2x3C-MAH | 30 | 21.6-88.56 | 15-40 | 5 | 21 | ||
| 4x3C-MAH | 30 | 28.8-158.4 | 7-53 | 5 | 28 | ||
| 6x4D-MAH | 60 | 72-331.2 | 11-64 | 5 | 44 | ||
| 8x6E-MAH | 120 | 126-720 | 6-62 | 5 | 63 | ||
| 10x8ST-MAH | 560 | 216-1051.2 | 9-64 | 5 | 76 | ||
| 12x10ST-MAH | 560 | 316.8-1620 | 10-66 | 5 | 86 | ||
| 14x12ST-MAH | 560 | 504-2455.2 | 10-75 | 5 | 90 | ||
*****More pump models please contact us*****
Packaging&Shipipping
Our Services
FAQ
Q: How can I make order online?
A: Send email or skype us.you can ask any question ,after we confirm the detail, we can make order.
Q: Do you have MOQ limit?
A: The MOQ is 1 sets.
Q: Which payments are acceptable?
A: T/T, L/C, Western Union, MoneyGram
Q: Which shipping terms are avaliable?
A: By sea, DHL, TNT( express for spare parts)
Q: How about the delivery time?
A: Delivery time is normally 3-7 working days after confirm the money.Depends on your quantity.
Q: What's your warranties?
A: 1 year after delivery
Q: Can I buy parts separately?
A: Yes,all of the parts can buyseparately.
Exhibition
Inquiry of Pump
( Please fill the blank)
1. Head: ____ meter
2.Capacity: _____m3/h
3. Liquid media: ____
4. PH: ______
5.Concentration: _____%
6. Temperature: _____℃
7. Specific density: ______kg/m3
