Customized Slurry Pump A05 Material

Customized slurry pump A05 material

The submersible slurry pump is a hydraulic machine in which the motor and the water pump are coaxially integrated into the medium. It is suitable for conveying liquids containing solid particles such as sand, cinder, tailings, etc. It is mainly used for the removal and conveying of mud liquids in metallurgy, mining, thermal power plants and other enterprises. It is an ideal substitute for traditional mud pumps.

Pump details

Pump bottom equipped with a filter. The pore size of the filter determines the maximum passing particle size, which can effectively prevent large particles from entering and damage impeller. Extend the service life of the pump.

The outlet of the pump is made of high chromium material, which can effectively prolong the life of the pump when conveying slurry medium. The outlet size ranges from 3.15 to 16 inches, and an external elbow can be connected when the working conditions require it.

The pump is equipped with protection:

1. Motor water inlet protection

2. Motor overheating protection

3. Water inlet protection of oil chamber

Make the slurry pump operate more safely!

Besides the high chrome iron impeller, we add a Mixing impeller to enlarge the pump solids Specific Gravity, mixing impeller material in high chrome iron Cr27% .

Wear-resistant submersible slurry pump This series of products is designed and manufactured by absorbing foreign advanced technology. The use of high-tech wear-resistant materials greatly increases the life of the equipment and reduces the frequency of maintenance. In addition to the main impeller, a set of stirring impellers are added at the bottom of the pump, which can spray the sedimented sludge into turbulent flow, and the formed high-concentration slurry is located at the suction port of the main impeller, so that the pump can achieve high concentration without auxiliary devices. delivery. The unique sealing device can effectively balance the pressure inside and outside the oil chamber, so that the pressure at both ends of the mechanical seal is balanced, which ensures the reliability of the mechanical seal to the greatest extent and greatly prolongs its service life. The motor adopts various protection measures such as overheating and water inflow detection, which can run safely for a long time under severe working conditions. Protection measures such as motor anti-condensation and bearing temperature measurement can also be added according to user requirements to meet the needs of users in different occasions.
