Submersible Sand Suction Pump

Submersible sand suction pump

1)Features:

Compared with common mud pumps and slurry pumps,  MSS series submersibel slurry motor pumps enjoy the characteristic as follows:

A: Submersible work without influence of suction head

B: No assistant vacuum pump, save our investment.

C: No noise, keep the silence of your work station.

D: With agitator, no need extra stirring devices, more convenience For operating.

E: It do not need to build pump house.

F: Directly works on the surface of the slurry, with more efficiency To dliver slurry

2)Application:

1. Delivering Liquid Sand, Coal Cinder Solid

2. Clearing The Mud In Lake, River, Sea

3. Dredging Widening Channel

3)Tech Date:

1. Name: MSS series  Submersible Slurry Pump

2. Pump Type: Submersible centrifugal slurry pumps

3. Power: Electric motor drive, hydraulic drive, excavator drive

4. Discharge Size: 80mm-400mm

5. Capacity: 25m3/h-2000m3/h

6. Head: 12m-60m
China Submersible Slurry Pumps River Dredging Submersible Slurry Pump

MSS submersible slurry pump is designed basing on the introduced foreign technology, fluid end parts (including casing, impeller, wear plate, agitator) are made by wear-resisting high chrome material which extends the pump service life. The increased paddle wheel (agitator) in the bottom of the main impeller can suspend the slurry to prevent clogging. Unique sealing device can effectively balance the pressure of mechanical seal inside and outside. Motor owns overheat protection and water detection to ensure the motor to operate safely and steady in the long-term under bad working conditions.
