Multistage pump, as the name suggests, is a pump composed of multiple impellers known for its high lift. Due to its high lift and pressure, it is often used as a lift pump. Its material can be divided into cast iron and cast steel according to different media. It is one of the common industrial pumps. Depump Technology provides Customized Multistage Pump.
Types of Multistage Pumps
Centrifugal multistage pumps can be divided into three categories, vertical multistage pumps, submersible multistage pumps, and horizontal multistage pumps. The horizontal multistage pump is divided into two categories according to different media temperature. This time we mainly introduce these two types of horizontal multistage pump. At the same time, we also provide horizontal customized multistage pump according to the specific needs of customers.
Type one: D Series Multistage Pump.
It is mainly used to transport clear water without solid particles or media with physical and chemical properties similar to clear water, and the medium temperature needs to be lower than 80 degrees Celsius.
The pump outlet is vertical and the pump inlet is horizontal.
Performance range
Q: 3.75-840m³/hr
H: 19-680meters
Type two: DG Series Multistage Pump.
DG series multistage pumps are mainly used for conveying low temperature or high temperature medium without solid particles with a temperature between minus 20 degrees Celsius and 150 degrees Celsius. The medium may be clear water or a medium with physical and chemical properties similar to clear water. It is usually used as boiler water feed pump in the field of paper mill, power factory, etc.
The inlet and outlet of the pump are in the same horizontal direction.
Performance range
Q: 3.75-185m³/hr
H: 50-684meters (Medium and low pressure)
H: 409-1450meters (sub-high pressure)
In addition to the D and DG series that can transport clean water, our multistage pumps also have the following pump types suitable for different media:
DF: can transport aggressive media
DY: Can transport oil or petroleum media
MD: can transport slurry containing particles
Also we accept customized multistage pump, just tell us the head, flow rate, voltage, we will send back the best solutions to you.
If you are interested in the above introduction or customized multistage pump, please send your inquiry to us.
And to know more info about our Customized Multistage Pump, please feel free to contact with us.
